Industrial Cobot KASSOW KR1205
Fast, flexible Kassow KR1205 industrial cobot with 1200 mm reach and 5 kg payload. Easy programming thanks to our special Kassow intuitive user interface.
Features:
Payload: 5 kg
Reach in all directions : 1200 mm
Weight : 25 kg
Degrees of freedom : 7
Repeatability : +/- 0.1 mm
Joint speed (deg/sec) : 225
IP specification : IP54
Documentation française
English documentationTechnical data Kassow KR1205 :
| General specifications | Kassow KR1205 |
|---|---|
| Span (mm) | 1200 |
| Payload (kg) | 5 |
| weight (kg) | 25 |
| Joint speed (deg/sec) | 1225 |
| Common ranges | J2 and J4: -70°/+180°. J1, J3, J5, J6 and J7: ±360°. |
| Joint brakes | Yes |
| Absolute encoders on joints | Yes |
| Repeatability (mm) | +/- 0,1 |
| Degrees of freedom | 7 |
| Footprint (mm) | 130×130 |
| Operating temperature (C ° ) | 0-45 |
| Body material | Anodized aluminum |
| Security | Kassow KR1205 |
|---|---|
| Protection class | IP54 |
| Working without shielding | Yes* |
| Shock control | Yes |
| 150 N safety force limit on tool | Yes |
| I/O controller | Kassow KR1205 |
|---|---|
| Digital outputs 24V (pcs) | 8 |
| Relay outputs (pcs) | 4 |
| Digital inputs 3-30V (pcs) | 16 |
| Analog I/O 0-10 V (pcs) | 2/2 |
| Analog I/O 4-20mA (pcs) | 2/2 |
*Any robot installation should always be assessed on an individual basis to determine its suitability for unshielded work. Contact us
