PARKER SERIES LINEAR BRUSHLESS MOTOR
I-FORCE TRILOGY

Parker Hannifin
Trilogy I-Force Linear Motors

Documentation française

English documentation

The Parker Trilogy I-Force range of brushless linear motors offers high forces and rapid acceleration in a compact package. With forces ranging from 24.5 N (5.5 lbf) to 878.6 N (197.5 lbf) continuous to 24.5 N (5.5 lbf) to 3928 N (883 lbf) peak, the Trilogy I-Force linear brushless motor family offers a superior combination of performance and size. I-Force's patented I-beam design, with overlapping windings, enables higher power density in a smaller motor, better heat dissipation and increased structural rigidity.

What's more, the design of the ironless (or air-core) linear motor exerts no attractive force on the magnets. This makes for easy installation and zero bumping during movement. Ultra-flexible cables are supplied as standard with I-Force motors. In addition, we offer modular magnetic tracks for unlimited travel lengths. Incredibly smooth motion, high precision and high force density make I-Force linear motors ideal for your demanding positioning needs.

More information on Parker.com

Overlapping winds :
- Increased force density
- Improved heat dissipation
- Reduced temperature rise
- A smaller, less expensive motor

No attractive force towards the magnets :
- Easier/safer assembly and handling, smoother movement (no cogging)

Uses thermally conductive epoxy with windings (Patented RE34674) :
- Better heat dissipation

Vacuum encapsulation process :
- Allows motors to be used in high-vacuum environments(Rated at 10^-6 torr, currently used in 10^-7 torr applications)

Modular magnetic track :
- Unlimited travel length

Built-in overheating thermostat or optional thermistor :
- Protects windings from overheating

Ultra-flexible cables :
- Longer cable life, good for millions of cycles
