KIT SERVOMOTORS - PARKER SERIES
HKW

Parker Hannifin

- Kit solution to simplify mechanics
- Very high speeds - up to 50,000 min-1
- Constant power operation up to 10 times base speed: no need to oversize the drive
- High dynamic performance and power density - increased productivity and compactness compared to induction motors
- Cold rotor with permanent magnets - reduced bearing overheating compared to asynchronous solutions, no expansion effect
- Compatible with the following drives - Siemens / Fanuc

Overview :

- Motor type: Permanent magnet servomotor in kit version
- Size: 85mm | 108mm | 155mm | 195mm | 242mm | 310mm
- Power range: 2.3 ... 230 kW
- Torque range: 4.2 ... 1250 Nm
- Speed range: 260 ... 23200 min-1 (base speed) / 16000 ... 50000 min-1 (max. speed)
- Supply voltage: 400-480VAC
- Number of poles: 4 | 6 | 8 | 16
- Cooling: Water-cooled
- Protection class: IP00
- Sensor: Sensorless | Resolver (optional)
- Marking: CE

- Machine tools

Documentation française

Documentation française

English documentation

Parker HKW series servo motor kits are high-performance motors for applications up to 230 kW. Delivered as kit motors for mechanical integration, HKW series motors enable high-torque operation up to a base speed, then constant-power operation above this speed up to high speeds.
